This document describes ValueRAM’s KVR32N22S6/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx16, memory module, based on four 1G x 16-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
| Buffered memory type | Unregistered (unbuffered) |
|---|---|
| CAS latency | 22 |
| Component for | PC/Server |
| ECC | No |
| Memory | 8 GB |
| Memory Type | DDR4 |
| JEDEC standard | Yes |
| Memory data transfer rate | 3200 MT/s |
| Memory form factor | 288-pin DIMM |
| Memory layout (modules x size) | 1 x 8 GB |
| Memory voltage | 1.2 V |
| Refresh row cycle time | 350 ns |
| Row active time | 32 ns |
| Row cycle time | 45.75 ns |
| SPD profile | Yes |
| Operating temperature (T-T) | 0 – 85 °C |
| Storage temperature (T-T) | -55 – 100 °C |
| Compliance certificates | RoHS |
| Doesn't contain | Halogen |
| Height | 31.25 mm |
| Width | 133.35 mm |
| Warranty | 5 years |
